RMC Internal Erosion Suite

The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed a set of toolboxes to help dam and levee safety risk assessors assess likelihood of several internal erosion types, including backward erosion piping, concentrated leak erosion, internal instability, and contract erosion. It also includes toolboxes to help assess the likelihood of breach due to enlargement of a concentrated leak pipe, to help assess erodibility parameters, and evaluation the likelihood of continuation of internal erosion using various filter criteria.
RMC Backward Erosion Piping (Initiation) Toolbox

RMC Backward Erosion Piping (Progression) Toolbox

RMC Breach Toolbox

RMC Concentrated Leak Erosion (Crack Width and Depth) Toolbox

The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Backward Erosion Piping (Initiation) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox deterministically and probabilistically assess the likelihood of initiation of backward erosion piping using blanket theory as described in TM 3-424 (1956) and EM 1110-2-1913 (2000), with corrections from ERDC/GSL TR-18-24 (Brandon et al. 2018), and first-order second-moment method of reliability analysis as described in ETL 1110-2-561 (2006).



The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Backward Erosion Piping (Progression) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox deterministically and probabilistically assess the likelihood of backward erosion piping progression (hydraulic condition) using the adapted Schmertmann (2000) method and Dutch adapted “piping rule” (Sellmeijer et al. 2011) in addition to creep ratio methods of Bligh (1910) and Lane (1935).



The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the Breach Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox can be used to help assess the likelihood of breach due to gross enlargement of a concentrated leak pipe using the excess shear stress equation, unravelling of the downstream slope due to flows through the rockfill, and sinkhole development, in addition to providing general guidance for assessing slope instability.



The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the Concentrated Leak Erosion (Crack Width and Depth) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox assess the crack width and depth using case histories, results of numerical modeling, empirical relationships, and published values in addition to the Fell et al. (2008) methodology. These parameters support the evaluation of initiation of concentrated leak erosion.

This is the RMC Backward Erosion Piping (Initiation) Toolbox version 1.5.

  This is the RMC Backward Erosion Piping (Progression) Toolbox version 1.1.   This is the RMC Breach Toolbox version 1.3.   This is the RMC Concentrated Leak Erosion (Crack Width and Depth) Toolbox version 1.4.


RMC Concentrated Leak Erosion (Initiation) Toolbox

RMC Erodibility Parameters Toolbox

RMC Filter Evaluation (Continuation) Toolbox

RMC Internal Instability (Suffusion) Toolbox

The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the Concentrated Leak Erosion (Initiation) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox deterministically and probabilistically assess the likelihood of initiation of concentrated leak erosion by estimating the hydraulic shear stress in pipes and transverse cracks in addition to the adapted methodology of Fell et al. (2008).



The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the Erodibility Parameters Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox assess the critical shear stress and erodibility coefficient using empirical relationships and published values based on field and laboratory testing. These parameters support the evaluation of initiation and progression of concentrated leak erosion, overtopping erosion, and some regression equations for embankment dam breach parameters.

  The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Filter Evaluation (Continuation) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox assess the particle retention and permeability criteria for filter materials It includes modern no erosion filter design criteria, Foster and Fell (2001) method for filters that do not meet modern filter design criteria, and the Fell et al. (2008) method for "continuing erosion" condition for constricted exits.

The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Internal Instability (Suffusion) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox deterministically and probabilistically assess the susceptibility to internal instability using the unified method for gap-graded and broadly graded cohesionless soils of Li and Fannin (2008), alternative method for broadly graded silt-sand-gravel soils of Wan and Fell (2008), modified Burenkova (1993) method of Wan and Fell (2008), and Burenkova (1993) method.

This is the RMC Concentrated Leak Erosion (Initiation) Toolbox version 1.3.

This is the RMC Erodibility Parameters Toolbox version 1.4.



This is the RMC Filter Evaluation (Continuation) Toolbox version 1.4.



This is the RMC Internal Instability (Suffusion) Toolbox version 1.3.




RMC Pipe Service Life (Flaw) Toolbox

RMC Soil Classification Toolbox

RMC Soil Contact Erosion (Initiation) Toolbox

The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the Pipe Service Life (Flaw) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox assess the remaining service life of steel, aluminum, concrete, iron, plastic, and clay pipes, especially for the pipe invert, when the existing condition is unknown due to lack of recent detailed inspection. This assessment supports the evaluation of internal migration into open defects in the pipe body.

  The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Soil Classification Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox assess the Unified Soil Classification (USCS) group symbol using the methods of ASTM D2487, generate soil plasticity charts and cumulative particle-size distribution plots, as well as perform statistical analysis of gradation data to support evaluation of backward erosion piping, soil contact erosion, and internal instability.   The U.S. Army Corps of Engineers (USACE) Risk Management Center (RMC) developed the RMC Soil Contact Erosion (Initiation) Toolbox as part of the RMC Internal Erosion Suite of Microsoft Excel spreadsheets to support risk assessments for dam and levee safety. The spreadsheet tools contained in this toolbox deterministically and probabilistically assess the likelihood of initiation of soil contact erosion using the methods of Guidoux et al. (2010) for sand, silt, and sand/clay mixtures below gravel and Brauns (1985) for sand below gravel.

This is the RMC Pipe Service Life (Flaw) Toolbox version 1.0.

  This is the RMC Soil Classification Toolbox version 1.1.

  This is the RMC Soil Contact Erosion (Initiation) Toolbox version 1.3.
